? Fully Compliant with JEDEC TSE2004av Specification

? Supply Voltage: 1.7V to 3.6V

? 2-wire Serial Interface I 2 C/SMBus Compatible

-   Up to 1 MHz Transfer Rate (I 2 C Fast Mode+) Supported

-   Bus Timeout Supported

? Schmitt Trigger, Filtered Inputs for Noise Suppression

? Operating Temperature Range: -40°C to +125°C

? Green Packaging Option (RoHS Compliant, Pb/Halogen-free)

-   8-Lead UDFN

? Temperature Sensor Accuracy

-   ± 0.5°C (typical) from +75°C to +95°C

-   ± 1°C (typical) from +40°C to +125°C

-   ± 2°C (typical) from -40°C to +125°C

? Temperature Sensor Resolution

-   10-bit Analog-to-digital Converter with 0.25°C/LSB Resolution (default)

-   Programmable 9-12 Bits

?  ADC Conversion Time: 125ms (maximum)

?  Programmable Temperature Hysteresis Threshold: 0, 1.5, 3 and 6.0°C

?  Low Operating Current

- Temperature Sensor Active (EEPROM Standby): 0.2mA (maximum)

- Temperature Sensor Shutdown (EEPROM Standby): 5μA (maximum)

?  Functionality Identical to WB34C04 SPD EEPROM

?  Software Data Protection on all Four 128-byte Blocks

?  Byte and Page Write Mode

-   Page Size up to 16 Bytes

?  Self-timed Write Cycle: 3ms (maximum)

?  Operating Temperature range: -40°C to +125°C

?  High Reliability

-   Endurance: 2,000,000 Write Cycles

-   Data Retention: 200 Years

?  Low Operating Current

-   SPD EEPROM Write Current: 1mA (maximum)

-   SPD EEPROM Read Current: 0.5mA (maximum)
